KriSemi’s GAGAN Receivers—as the name suggests—the GPS receiver along with SBAS (GAGAN) Satellites data produce more accurate positioning than normal GPS receivers. This Handheld Device is power packed with many features in it, yet simple to use and user-friendly, it takes only a few steps to get started.
Note :
Requires App/software on any android smart phone/windows PC to connect and get the live stream of NMEA data on to the host.
Microcontroller based Gagan Enabled Bluetooth GPS Device.
Battery power indicators.
GPS - 3D/DGPS and Gagan fix indicators.
Data Logging every 2sec in user accessible Micro SD Card.
Approximately 4GB SDcard can store up to 100 days of continuous data.
Software: U-Center is a powerful tool providing data analysis of
MEA statements, real time or stored data on windows.
Rechargeable Li-ion battery up to 20hrs of continuous backup.
Battery over-charge and over-discharge safety included.
Beeper to indicate device functioning and Data Logging.
Four LEDs Indications for functionality and status of the device.
Light weight, safe and reliable, portable handheld device.
Geo- Tagging
Navigation
Data Logger
Geo - Data Analysis
Real Time Location Tracking and much more.....
Ver.2.0(Classic) available with CSR BlueCore/TI CC2540.
Password Protection: Yes (4 digits pin User Customized or default).
Pair Devices memory: up to 40 No’s.
Distance Covered: 10m.
Sensitivity: ≤-84dBm.
Li-ion battery (2500mAH)
Charger Required: Max 5V-1Amp Micro USB
(Any mobile adapter with micro USB).
Operating Temperature: -20 ̊c to +85 ̊c
NMEA protocol: supports 2.3 or greater
Update rate: 1sec (max 5Hz/0.2Sec)
Inbuilt Antenna: 25×25mm patch antenna (5dBm)
Channels can acquire: 50
Acquisition Channels: 12
Frequency: L1 C/A 1572.42MHz (±10%)
SBAS: WAAS/EGNOS/MSAS/GAGAN/QZSS
Accuracy: GPS: 3.0m CEP, SBAS: 2.0m CEP
Cold starts: >35sec, Hot Starts: 2sec
Sensitivity: Tracking: -161dBm
Stand-by/low battery: 0.1mA
Functioning: ~120mA
High Impact UL94-HB ABS Material.
